SDA02H0SBD
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Switches / DIP Switches
Description
Slide (Standard) SDA 2 Surface Mount Dip Switch 0m 25mA 24V 50mOhm
PDF
/
Buying Options
Total Price: USD $13.83
Unit Price: USD $13.82535
≥1 USD $13.82535
≥10 USD $11.34395
≥100 USD $10.9896
≥500 USD $10.6343
≥1000 USD $10.27995
Inventory: 1331
Minimum: 1
-
+
Technical Details
Technical
Orientation Straight
Terminal Pitch 2.54mm
Current Rating 25mA
Contact Finish Gold
Termination Style Gull Wing
Actuator Type Slide (Standard)
Circuit SPST
Contact Resistance 50mOhm
Max Current Rating 100mA
Electrical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Mechanical Life 1,000 Cycles
Washable No
Actuator Level Flush, Recessed
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Number of Positions 2
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SDA
Published 2011
Packaging Tube
Operating Temperature -40°C~85°C
Dimensions
Length 0.278 7.06mm
Actuator Length 0m
Height Above Board 0.175 4.45mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Actuator Material Polyamide
Body Material Polyphenylene Sulfide (PPS)
Package / Case DIP
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 15 Weeks
