SD08H0B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 100MA 25V
PDF
/
Buying Options
Total Price: USD $2.79
Unit Price: USD $2.7896
≥1 USD $2.7896
≥10 USD $2.62768
≥100 USD $2.389024
≥500 USD $2.070552
≥1000 USD $1.877146
≥3000 USD $1.740622
Inventory: 573
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material Beryllium Copper
Mount Through Hole
Mounting Type Through Hole
Body Material Polyphthalamide (PPA)
Actuator Material Nylon
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2011
Series SD
Feature Tape Seal
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Number of Positions 8
Voltage - Rated 25VDC
Voltage - Rated DC 25V
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Depth 8.5mm
Current Rating 100mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Max Current Rating 100mA
Electrical Life 2,000 Cycles
Max Voltage Rating (DC) 25V
Mechanical Life 2,000 Cycles
Washable Yes
Actuator Level Flush, Recessed
Dimensions
Length 0.858 21.80mm
Actuator Length 0m
Height Above Board 0.178 4.52mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
