SD07H1SB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 100MA 25V
PDF
/
Buying Options
Total Price: USD $6.72
Unit Price: USD $6.718109
≥1 USD $6.718109
≥200 USD $2.599542
≥500 USD $2.508952
≥1000 USD $2.463
Inventory: 1285
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Above Board 0.180 4.57mm
Actuator Length 250μm
Length 0.758 19.25mm
Technical
Actuator Level Raised
Washable Yes
Mechanical Life 2,000 Cycles
Max Voltage Rating (DC) 25V
Throw Configuration SPST
Electrical Life 2,000 Cycles
Max Current Rating 100mA
Circuit SPST
Actuator Type Slide (Standard)
Termination Style Gull Wing
Contact Finish Gold
Current Rating 100mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Current Rating (Amps) 100mA
Voltage - Rated DC 25V
Voltage - Rated 25VDC
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 7
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tape Seal
Series SD
Published 2011
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Actuator Material Nylon
Body Material Polyphthalamide (PPA)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 13 Weeks
