SD06H0SBD
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
DIP Switches / SIP Switches SW DIP ON OFF SPST 6FLUSH SD 0.1A 25VDC
PDF
/
Buying Options
Total Price: USD $3.57
Unit Price: USD $3.567149
≥1 USD $3.567149
≥200 USD $1.381171
≥500 USD $1.332594
≥1000 USD $1.308961
Inventory: 4809
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material Beryllium Copper
Mount Surface Mount
Mounting Type Surface Mount
Body Material Polyphthalamide (PPA)
Actuator Material Nylon
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2012
Series SD
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Number of Positions 6
Voltage - Rated 25VDC
Voltage - Rated DC 25V
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 16.71mm
Current Rating 100mA
Contact Finish Gold
Termination Style Gull Wing
Actuator Type Slide (Standard)
Circuit SPST
Max Current Rating 100mA
Electrical Life 2,000 Cycles
Max Voltage Rating (DC) 25V
Mechanical Life 2,000 Cycles
Washable No
Actuator Level Flush, Recessed
Life (Cycles) 2000 cycles
Dimensions
Length 0.658 16.71mm
Actuator Length 0m
Height Above Board 0.155 3.94mm
Compliance
RoHS Status ROHS3 Compliant
