SD05H1SBR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Switch DIP OFF ON SPST 5 Raised Slide 0.1A 25VDC Gull Wing 2000Cycles/SwitchCycles 2.54mm SMD T/R
PDF
/
Inventory: 4412
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Above Board 0.180 4.57mm
Actuator Length 250μm
Length 0.558 14.17mm
Technical
Actuator Level Raised
Washable Yes
Mechanical Life 2,000 Cycles
Max Voltage Rating (DC) 25V
Electrical Life 2,000 Cycles
Max Current Rating 100mA
Circuit SPST
Actuator Type Slide (Standard)
Termination Style Gull Wing
Contact Finish Gold
Current Rating 100mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 25V
Voltage - Rated 25VDC
Number of Positions 5
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Tape Seal
Series SD
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Actuator Material Nylon
Body Material Polyphthalamide (PPA)
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 13 Weeks
