RTE1601V44
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH ROTARY 16POS HEX RT ANGLE
PDF
/
Inventory: 5998
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.335 8.50mm
Actuator Length 7.5mm
Width 8mm
Length 0.291 7.40mm
Height 8.5mm
Technical
Actuator Level Raised
Washable No
Mechanical Life 20,000 Steps
Max Voltage Rating (DC) 30V
Throw Configuration SP16T
Max Current Rating 100mA
Contact Resistance 100mOhm
Circuit Hexadecimal
Actuator Type Rotary with Shaft
Termination Style PC Pin
Contact Finish Gold
Current Rating 100mA
Orientation Right Angle
Pitch 0.100 2.54mm Full
Current Rating (Amps) 100mA
Voltage - Rated DC 30V
Voltage - Rated 30VDC
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Positions 16
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series RTE
Published 2007
Packaging Tube
Operating Temperature -25°C~85°C
Physical
Actuator Material Polyamide, Thermoplastic
Body Material Polyphenylene Sulfide (PPS)
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
Supply Chain
Factory Lead Time 7 Weeks
