RTE1002N24

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / DIP Switches
Description Rotary with Shaft RTE 10 Through Hole Dip Switch 3.8mm 100mA 30V 100mOhm
PDF
/
Inventory: 940
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Circuit BCD Complement
Contact Resistance 100mOhm
Throw Configuration SP10T
Max Voltage Rating (DC) 30V
Mechanical Life 20,000 Steps
Washable No
Actuator Level Raised
Actuator Type Rotary with Shaft
Termination Style PC Pin
Contact Finish Gold
Current Rating 100mA
Orientation Straight
Pitch 0.100 2.54mm Full
Current Rating (Amps) 100mA
Voltage - Rated DC 30V
Voltage - Rated 30VDC
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Positions 10
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series RTE
Published 2012
Packaging Tube
Operating Temperature -25°C~85°C

Dimensions

Length 0.291 7.40mm
Actuator Length 3.8mm
Height Above Board 0.321 8.15mm

Compliance

RoHS Status ROHS3 Compliant

Physical

Actuator Material Polyamide, Thermoplastic
Body Material Polyphenylene Sulfide (PPS)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Bronze

Supply Chain

Factory Lead Time 14 Weeks
