RTE1000V24
RoHS
/
Package /
Category Switches / DIP Switches
Description
Switch DIP SP10T 10 Flush Screwdriver 0.1A 30VDC PC Pins 20000Cycles Thru-Hole Box
PDF
/
Buying Options
Total Price: USD $3.03
Unit Price: USD $3.026235
≥1 USD $3.026235
≥150 USD $1.207868
≥450 USD $1.167168
≥1050 USD $1.147475
Inventory: 2240
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.335 8.50mm
Actuator Length 0m
Length 0.291 7.40mm
Technical
Actuator Level Flush, Recessed
Washable No
Mechanical Life 20,000 Steps
Max Voltage Rating (DC) 30V
Throw Configuration SP10T
Max Current Rating 100mA
Contact Resistance 100mOhm
Circuit BCD Complement
Actuator Type Rotary for Tool
Termination Style PC Pin
Contact Finish Gold
Current Rating 100mA
Orientation Right Angle
Pitch 0.100 2.54mm Full
Current Rating (Amps) 100mA
Voltage - Rated DC 30V
Voltage - Rated 30VDC
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Positions 10
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series RTE
Published 2012
Packaging Bulk
Operating Temperature -25°C~85°C
Physical
Actuator Material Polyamide, Thermoplastic
Body Material Polyphenylene Sulfide (PPS)
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold
Contact Material Bronze
Supply Chain
Factory Lead Time 11 Weeks
