RTE0211N05
RoHS
/
Package /
Category Switches / DIP Switches
Description
Switch DIP SPDT 2 Extended Shaft 0.1A 50VDC PC Pins 1500Cycle 2.54mm Thru-Hole Tube
PDF
/
Inventory: 4228
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.463 11.75mm
Actuator Length 7.5mm
Length 0.291 7.40mm
Technical
Actuator Level Raised
Washable No
Mechanical Life 1,500 Steps
Max Voltage Rating (DC) 50V
Throw Configuration SPDT
Contact Resistance 100mOhm
Circuit SPDT
Actuator Type Rotary with Shaft
Termination Style PC Pin
Contact Finish Silver
Current Rating 100mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Current Rating (Amps) 100mA
Voltage - Rated DC 50V
Voltage - Rated 50VDC
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Number of Positions 2
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series RTE
Packaging Tube
Operating Temperature -25°C~85°C
Physical
Actuator Material Polyamide, Thermoplastic
Body Material Polyphenylene Sulfide (PPS)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Silver
Contact Material Bronze
