CRD16RM0AK
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH ROTARY DIP HEX 0.40VA 20V
PDF
/
Buying Options
Total Price: USD $8.7
Unit Price: USD $8.700588
≥1 USD $8.700588
≥210 USD $3.471308
≥490 USD $3.355772
≥1015 USD $3.298005
Inventory: 2261
Minimum: 1
-
+
Technical Details
Physical
Contact Material Beryllium Copper
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole, Right Angle
Body Material Polyphenylene Sulfide (PPS)
Actuator Material Nylon, Polyamide
Technical
Operating Temperature -20°C~85°C
Packaging Tube
Published 2001
Series CRD
Feature Process Sealed
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PCB
Number of Positions 16
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Voltage - Rated 20VAC/DC
Current Rating (Amps) 0.4VA
Pitch 0.100 2.54mm Full
Orientation Right Angle
Terminal Pitch 2.54mm
Contact Finish Gold
Termination Style PC Pin
Actuator Type Rotary for Tool
Circuit Hexadecimal
Contact Resistance 100mOhm
Max Voltage Rating (AC) 20V
Electrical Life 20,000 Steps
Throw Configuration SP16T
Max Voltage Rating (DC) 20V
Mechanical Life 30,000 Steps
Washable Yes
Actuator Level Flush, Recessed
Dimensions
Length 0.393 10.00mm
Actuator Length 0m
Height Above Board 0.414 10.51mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
