CD16RM0CK
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH ROTARY DIP HEX 0.40VA 20V
PDF
/
Buying Options
Total Price: USD $7.57
Unit Price: USD $7.568869
≥1 USD $7.568869
≥180 USD $3.020983
≥495 USD $2.91989
≥990 USD $2.869999
Inventory: 1418
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper Alloy
Contact Plating Nickel
Mount Through Hole
Mounting Type Through Hole
Body Material Polyphenylene Sulfide (PPS)
Technical
Operating Temperature -25°C~85°C
Packaging Tube
Published 2003
Series CD
Feature Process Sealed
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PCB
Number of Positions 16
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Voltage - Rated 20VAC/DC
Current Rating (Amps) 0.4VA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Actuator Type Rotary for Tool
Circuit Hexadecimal
Max Voltage Rating (AC) 20V
Electrical Life 20,000 Steps
Throw Configuration SP16T
Max Voltage Rating (DC) 20V
Mechanical Life 20,000 Steps
Washable Yes
Actuator Level Flush, Recessed
Dimensions
Length 0.315 8.00mm
Height Above Board 0.168 4.27mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
