CD16RL1CB

C&K
RoHS
/
Package /
Category Switches / DIP Switches
Description Rotary with Shaft CD 16 Through Hole Dip Switch 3.2mm 0.4VA 20V 50mOhm
PDF
/
Buying Options
Total Price: USD $8.62
Unit Price: USD $8.61525
≥1 USD $8.61525
≥180 USD $3.437172
≥480 USD $3.32295
≥1020 USD $3.266495
Inventory: 1724
Minimum: 1
-
+

Technical Details

Physical

Contact Material Copper Alloy
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Body Material Polyphenylene Sulfide (PPS)
Actuator Material Polymer

Technical

Operating Temperature -25°C~85°C
Packaging Tube
Published 2010
Series CD
Feature Process Sealed
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
Number of Positions 16
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Voltage - Rated 20VAC/DC
Current Rating (Amps) 0.4VA
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Contact Finish Gold
Termination Style PC Pin
Actuator Type Rotary with Shaft
Circuit Hexadecimal
Contact Resistance 50mOhm
Max Voltage Rating (AC) 20V
Electrical Life 20,000 Steps
Throw Configuration SP16T
Max Voltage Rating (DC) 20V
Mechanical Life 20,000 Steps
Washable Yes
Actuator Level Raised
Life (Cycles) 20000 cycles

Dimensions

Length 0.315 8.00mm
Actuator Length 3.2mm
Height Above Board 0.295 7.50mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
