BPA09SB

C&K
RoHS
RoHS RoHS compliant
Package DIP
Category Switches / DIP Switches
Description SWITCH DIP SIDE ACT SMD 9POS 5V
PDF
/
Buying Options
Total Price: USD $3.48
Unit Price: USD $3.476
≥1 USD $3.476
≥10 USD $3.32992
≥100 USD $3.0404
≥500 USD $2.635054
≥1000 USD $2.38898
≥3000 USD $2.215215
Inventory: 469
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 14 Weeks

Physical

Contact Material Beryllium Copper
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Package / Case DIP
Body Material Polyphenylene Sulfide (PPS)
Actuator Material Polyamide

Technical

Operating Temperature -20°C~85°C
Packaging Tube
Published 2010
Series BPA
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Number of Positions 9
Voltage - Rated 5VDC
Voltage - Rated DC 5V
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Current Rating 100mA
Contact Finish Gold
Termination Style Gull Wing
Actuator Type Piano
Circuit SPST
Contact Resistance 50mOhm
Max Current Rating 100mA
Electrical Life 1,000 Cycles
Max Voltage Rating (DC) 24V
Mechanical Life 1,000 Cycles
Washable Yes
Actuator Level Raised
Life (Cycles) 1000 cycles

Dimensions

Length 0.976 24.79mm
Actuator Length 2.1mm
Height Above Board 0.274 6.95mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
