BP01KT
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 100MA 5V
PDF
/
Inventory: 7707
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole, Right Angle
Body Material Polyester (PET), Glass Filled
Actuator Material Glass, Polyester
Technical
Operating Temperature -20°C~60°C
Packaging Tube
Published 1997
Series BP
Feature Epoxy Sealed Terminals, Tape Seal
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Number of Positions 1
Max Operating Temperature 60°C
Min Operating Temperature -20°C
Voltage - Rated 5VDC
Current Rating (Amps) 100mA
Pitch 0.100 2.54mm Full
Orientation Straight
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Electrical Life 2,000 Cycles
Throw Configuration SPST
Max Voltage Rating (DC) 24V
Mechanical Life 2,000 Cycles
Washable Yes
Actuator Level Raised
Dimensions
Length 0.206 5.23mm
Actuator Length 2mm
Height Above Board 0.315 8.00mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
