BDB09

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / DIP Switches
Description DIP 9P STANDARD VERTICAL PROFILE
PDF
/
Inventory: 7878
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Electrical Life 10,000 Cycles
Mechanical Life 10,000 Cycles
Washable Yes
Actuator Level Raised
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 25mA
Voltage - Rated 25VDC
Number of Positions 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series BDB
Packaging Tube
Operating Temperature -40°C~85°C

Dimensions

Length 0.980 24.89mm
Height Above Board 0.274 6.95mm

Compliance

RoHS Status ROHS3 Compliant

Physical

Body Material Polyamide (PA46), Nylon 4/6
Mounting Type Through Hole
Contact Material Phosphor Bronze

Supply Chain

Factory Lead Time 8 Weeks
