BD06AV
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 100MA 5V
PDF
/
Buying Options
Total Price: USD $2.25
Unit Price: USD $2.2528
≥1 USD $2.2528
≥10 USD $2.156
≥100 USD $1.968164
≥500 USD $1.705686
≥1000 USD $1.650018
Inventory: 1200
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Above Board 0.380 9.64mm
Actuator Length 900μm
Length 0.680 17.27mm
Technical
Actuator Level Raised
Washable Yes
Contact Current Rating 100mA
Mechanical Life 10,000 Cycles
Max Voltage Rating (DC) 25V
Electrical Life 10,000 Cycles
Max Current Rating 100mA
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Current Rating 100mA
Depth 11.69mm
Terminal Pitch 2.54mm
Orientation Right Angle
Pitch 0.100 2.54mm Full
Voltage - Rated DC 25V
Voltage - Rated 5VDC
Number of Positions 6
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series BD
Published 2001
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Actuator Material Glass, Nylon
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Package / Case DIP
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold, Silver, Tin
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 16 Weeks
