PT65727
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SW ROTARY DIP OCT COMP 150MA 24V
PDF
/
Buying Options
Total Price: USD $15.87
Unit Price: USD $15.872961
≥1 USD $15.872961
≥200 USD $6.33343
≥500 USD $6.122053
≥1000 USD $6.017021
Inventory: 5929
Minimum: 1
-
+
Technical Details
Technical
Number of Positions 8
Voltage - Rated 24VDC
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Sealed - Flux Protection
JESD-609 Code e4
Series PT65
Packaging Tube
Operating Temperature -20°C~70°C
Actuator Level Flush, Recessed
Washable Yes
Number of Switch Sections 1
Switch Type ROTARY CODED SWITCH
Mechanical Life 10,000 Cycles
Contact Voltage(DC)-Max 24V
Contact Current(DC)-Max 0.4A
Circuit Octal Complement
Actuator Type Rotary for Tool
Body Breadth 10 mm
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 150mA
Physical
Body Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 8 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.256 6.50mm
Body Height 6.5mm
Length 0.393 10.00mm
