PT65526L508
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Rotary with Knob PT65 8 Through Hole Right Angle Dip Switch 10mm 0.4A 24V 45deg
PDF
/
Buying Options
Total Price: USD $21.48
Unit Price: USD $21.479044
≥1 USD $21.479044
≥200 USD $8.570611
≥500 USD $8.284399
≥1000 USD $8.142606
Inventory: 2800
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole, Right Angle
Body Material Thermoplastic
Terminal Material BRASS
Technical
Operating Temperature -20°C~70°C
Packaging Tube
Series PT65
JESD-609 Code e4
Feature Sealed - Flux Protection
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 8
Voltage - Rated 24VDC
Additional Feature O-RING Si RUBBER ACTUATOR SEAL
Current Rating (Amps) 150mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Actuator Type Rotary with Knob
Circuit Octal
Insulation Resistance 100000000Ohm
Contact Current(DC)-Max 0.4A
Sealing MOLDED
Contact Voltage(DC)-Max 24V
Electrical Life 10000 Cycle(s)
Mechanical Life 10,000 Cycles
Switch Type ROTARY CODED SWITCH
Contact Timing BREAK-BEFORE-MAKE
Index Angle 45 deg
Number of Switch Sections 1
PCB Hole Count 6
Contact Function ON-OFF
Washable Yes
Actuator Level Raised
Solderability WAVE
Washability SOLVENT
Dimensions
Length 0.393 10.00mm
Body Height 10mm
Height Above Board 0.394 10.00mm
Compliance
RoHS Status ROHS3 Compliant
