PT65521L254

APEM Inc.
RoHS
RoHS RoHS compliant
Package /
Category Switches / DIP Switches
Description Rotary with Knob PT65 4 Through Hole Right Angle Dip Switch 4.4mm 150mA 24V 90deg
PDF
/
Buying Options
Total Price: USD $21.48
Unit Price: USD $21.479044
≥1 USD $21.479044
≥200 USD $8.570611
≥500 USD $8.284399
≥1000 USD $8.142606
Inventory: 7673
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole, Right Angle
Body Material Thermoplastic
Actuator Material Polyoxymethylene
Terminal Material BRASS

Technical

Operating Temperature -20°C~70°C
Packaging Tube
Series PT65
JESD-609 Code e4
Feature Sealed - Flux Protection
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
ECCN Code EAR99
Number of Positions 4
Voltage - Rated 24VDC
Additional Feature O-RING Si RUBBER ACTUATOR SEAL
HTS Code 8536.50.90.20
Current Rating (Amps) 150mA
Pitch 0.100 2.54mm Full
Orientation Right Angle
Terminal Pitch 2.54mm
Contact Finish Gold
Termination Style PC Pin
Body Breadth 6.8 mm
Actuator Type Rotary with Knob
Circuit SP4T
Contact Resistance 0.08mOhm
Insulation Resistance 100000000Ohm
Sealing MOLDED
Electrical Life 10000 Cycle(s)
Max Voltage Rating (DC) 24V
Mechanical Life 10,000 Cycles
Switch Type ROTARY CODED SWITCH
Contact Timing BREAK-BEFORE-MAKE
Index Angle 90 deg
Number of Switch Sections 1
PCB Hole Count 6
Contact Function ON-ON
Washable Yes
Actuator Level Raised
Solderability WAVE
Washability SOLVENT

Dimensions

Length 0.393 10.00mm
Body Height 10mm
Actuator Length 4.4mm
Height Above Board 0.394 10.00mm

Compliance

RoHS Status ROHS3 Compliant
