P65SMT701
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SWITCH ROTARY DIP BCD 200MA 50V
PDF
/
Buying Options
Total Price: USD $6.82
Unit Price: USD $6.82
≥1 USD $6.82
≥10 USD $6.51376
≥100 USD $5.521472
≥500 USD $5.118168
≥1000 USD $4.652877
≥3000 USD $4.311666
Inventory: 79
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.268 6.80mm
Body Height 6.8072mm
Length 0.393 10.00mm
Technical
Body Color BLACK
Actuator Level Flush, Recessed
Washable Yes
Index Angle 36 deg
Contact (DC) Max Rating R Load 0.1A@42VDC
Switching Voltage 42V
Contact Current Rating 150mA
Switch Type ROTARY CODED SWITCH
Mechanical Life 30,000 Cycles
Electrical Life 30000 Cycle(s)
Contact Current(DC)-Max 0.1A
Contact Resistance 0.08mOhm
Circuit BCD
Actuator Type Rotary for Tool
Termination Style Gull Wing
Contact Finish Gold
Current Rating 200mA
Pitch 0.100 2.54mm Full
Voltage - Rated DC 50V
Voltage - Rated 50VDC
Number of Positions 10
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series P65
Packaging Tube
Operating Temperature -60°C~125°C
Physical
Body Material Thermoplastic
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
