NDI03S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) NDI 3 Through Hole Dip Switch 0.197 5.00mm 0.025A 24V 0.05mOhm
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.106495
≥1 USD $1.106495
≥10 USD $1.043868
≥100 USD $0.984774
≥500 USD $0.929028
≥1000 USD $0.876449
Inventory: 1246
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Insulation Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Terminal Material BRASS
Technical
Operating Temperature -20°C~85°C
Packaging Tube
Series NDI
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Positions 3
Voltage - Rated 24VDC
Current Rating (Amps) 25mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Body Breadth 6.985 mm
Actuator Type Slide (Standard)
Circuit SPST
Contact Resistance 0.05mOhm
Insulation Resistance 100000000Ohm
Contact Current(DC)-Max 0.025A
Sealing MOLDED
Contact Voltage(DC)-Max 24V
Dielectric Withstanding Voltage 500VDC V
Electrical Life 2,000 Cycles
Mechanical Life 2,000 Cycles
PCB Hole Count 6
Contact Function ON-OFF
Washable No
Actuator Level Raised
Solderability WAVE
Body Color BLACK
Washability SOLVENT
Dimensions
Length 0.337 8.56mm
Height Above Board 0.197 5.00mm
Compliance
RoHS Status ROHS3 Compliant
