NDI02H
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) NDI 2 Through Hole Dip Switch 600mum 25mA 500VDC V 50mOhm
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.007765
≥1 USD $1.007765
≥10 USD $0.950726
≥100 USD $0.896912
≥500 USD $0.846136
≥1000 USD $0.798239
Inventory: 8481
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Insulation Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Actuator Material Nylon
Terminal Material BRASS
Technical
Operating Temperature -20°C~85°C
Packaging Tube
Series NDI
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
ECCN Code EAR99
Number of Positions 2
Voltage - Rated 24VDC
HTS Code 8536.50.90.65
Current Rating (Amps) 25mA
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Contact Resistance 50mOhm
Insulation Resistance 100000000Ohm
Sealing MOLDED
Dielectric Withstanding Voltage 500VDC V
Electrical Life 2,000 Cycles
Max Voltage Rating (DC) 24V
Mechanical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 1
PCB Hole Count 4
Contact Function ON-OFF
Washable No
Actuator Level Raised
Solderability WAVE
Body Color BLACK
Washability SOLVENT
Dimensions
Length 0.237 6.02mm
Body Height 4.4mm
Actuator Length 600μm
Height Above Board 0.197 5.00mm
Compliance
RoHS Status ROHS3 Compliant
