DS05T
RoHS
/
Package DIP
Category Switches / DIP Switches
Description
SWITCH SLIDE DIP SPST 50MA 24V
PDF
/
Buying Options
Total Price: USD $3.34
Unit Price: USD $3.341331
≥1 USD $3.341331
≥192 USD $1.333906
≥512 USD $1.289268
≥992 USD $1.266949
Inventory: 5069
Minimum: 1
-
+
Technical Details
Physical
Contact Material Phosphor Bronze
Mount Through Hole
Mounting Type Through Hole
Package / Case DIP
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Actuator Material Glass fibre, Polybutylene
Technical
Operating Temperature -20°C~70°C
Packaging Tube
Series DS
Feature Epoxy Sealed Terminals, Tape Seal
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Number of Positions 5
Voltage - Rated 24VDC
Voltage - Rated DC 24V
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Current Rating 50mA
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Contact Resistance 50mOhm
Electrical Life 2,000 Cycles
Max Voltage Rating (DC) 24V
Mechanical Life 5,000 Cycles
Washable Yes
Actuator Level Raised
Dimensions
Length 0.559 14.20mm
Actuator Length 1.25mm
Height Above Board 0.271 6.88mm
Compliance
RoHS Status RoHS Compliant
