DPL10T
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH DIL PIANO SPST 50MA 24V
PDF
/
Inventory: 9536
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Height Above Board 0.402 10.20mm
Length 1.061 26.95mm
Technical
Washability SOLVENT
Actuator Angle 30 deg
Body Color BLACK
Solderability WAVE
Actuator Level Raised
Washable Yes
Contact Function ON-OFF
PCB Hole Count 20
Number of Switch Sections 10
Mechanical Life 5,000 Cycles
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VDC V
Contact Voltage(DC)-Max 24V
Sealing TOP TAPE SEALED
Contact Current(DC)-Max 0.05A
Contact Resistance 0.05mOhm
Circuit SPST
Actuator Type Piano
Termination Style PC Pin
Contact Finish Gold
Reach Compliance Code compliant
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
HTS Code 8536.50.90.65
Additional Feature EXTENDED ACTUATOR
Voltage - Rated 24VDC
Number of Positions 10
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Epoxy Sealed Terminals, Tape Seal
JESD-609 Code e4
Series DPL
Packaging Tube
Operating Temperature -20°C~70°C
Physical
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Housing Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Insulation Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Mounting Feature THROUGH HOLE-RIGHT ANGLE
Surface Mount NO
Mounting Type Through Hole, Right Angle
Contact Material Phosphor Bronze
