DPL04U
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH DIL PIANO SPST 50MA 24V
PDF
/
Inventory: 8612
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole, Right Angle
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -20°C~70°C
Packaging Tube
Series DPL
Feature Epoxy Sealed Terminals
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Positions 4
Voltage - Rated 24VDC
Current Rating (Amps) 50mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Actuator Type Piano
Circuit SPST
Electrical Life 2,000 Cycles
Mechanical Life 5,000 Cycles
Washable No
Actuator Level Raised
Dimensions
Length 0.461 11.71mm
Height Above Board 0.402 10.20mm
