DP05
RoHS
/
Package /
Category Switches / DIP Switches
Description
SWITCH DIL PIANO SPST 50MA 24V
PDF
/
Inventory: 2424
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole, Right Angle
Surface Mount NO
Mounting Feature THROUGH HOLE-RIGHT ANGLE
Insulation Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Housing Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Technical
Operating Temperature -20°C~70°C
Packaging Tube
Series DP
JESD-609 Code e4
Feature Epoxy Sealed Terminals
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 5
Voltage - Rated 24VDC
Additional Feature RECESSED ACTUATOR
Current Rating (Amps) 50mA
Pitch 0.100 2.54mm Full
Reach Compliance Code compliant
Contact Finish Gold
Termination Style PC Pin
Body Breadth 10.8 mm
Actuator Type Piano
Circuit SPST
Insulation Resistance 100000000Ohm
Sealing EPOXY TERMINAL SEALED
Contact Voltage(DC)-Max 24V
Electrical Life 2,000 Cycles
Mechanical Life 5,000 Cycles
Number of Switch Sections 5
PCB Hole Count 10
Contact Function ON-OFF
Washable No
Actuator Level Flush, Recessed
Solderability WAVE
Body Color BLACK
Washability SOLVENT
Dimensions
Length 0.561 14.25mm
Body Height 10.2mm
Height Above Board 0.402 10.20mm
