DM06
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Switches / DIP Switches
Description
Slide (Standard) DM 6 Surface Mount Dip Switch 700mum 0.025A 500VDC V 50mOhm
PDF
/
Inventory: 10015
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.173 4.40mm
Actuator Length 700μm
Body Height 3mm
Length 0.637 16.18mm
Technical
Washability SOLVENT
Body Color BLACK
Solderability WAVE
Actuator Level Raised
Washable No
Contact Function ON-OFF
Number of Switch Sections 1
Mechanical Life 2,000 Cycles
Max Voltage Rating (DC) 24V
Electrical Life 2,000 Cycles
Dielectric Withstanding Voltage 500VDC V
Sealing MOLDED
Contact Current(DC)-Max 0.025A
Insulation Resistance 100000000Ohm
Contact Resistance 50mOhm
Circuit SPST
Actuator Type Slide (Standard)
Termination Style Gull Wing
Contact Finish Gold
Current Rating 25mA
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Voltage - Rated DC 24V
Voltage - Rated 24VDC
Number of Positions 6
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Series DM
Packaging Tube
Operating Temperature -20°C~85°C
Physical
Terminal Material BRASS
Actuator Material Nylon
Body Material Polyphenylene Sulfide (PPS), Glass Filled
Insulation Material GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Package / Case DIP
Mounting Type Surface Mount
Mount Surface Mount
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 8 Weeks
