DA08BTN
RoHS
/
Package /
Category Switches / DIP Switches
Description
Slide (Standard) DA 8 Through Hole Right Angle Dip Switch 0.390 9.90mm 50mA 24VDC -20C~70C
PDF
/
Inventory: 6700
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Height Above Board 0.390 9.90mm
Length 0.859 21.82mm
Technical
Actuator Level Raised
Washable Yes
Mechanical Life 5,000 Cycles
Electrical Life 2,000 Cycles
Circuit SPST
Actuator Type Slide (Standard)
Termination Style PC Pin
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 50mA
Voltage - Rated 24VDC
Number of Positions 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Epoxy Sealed Terminals, Tape Seal
Series DA
Packaging Tube
Operating Temperature -20°C~70°C
Physical
Body Material Polybutylene Terephthalate (PBT), Glass Filled
Mounting Type Through Hole, Right Angle
Contact Material Phosphor Bronze
