RLZTE-1122B
RoHS
RoHS compliant
RoHS compliantPackage DO-213AC, MINI-MELF, SOD-80
Category Discrete Semiconductor Products / Diodes - Zener - Single
Description
DIODE ZENER 21.2V 500MW LLDS
PDF
/
Buying Options
Total Price: USD $0.08
Unit Price: USD $0.08075
≥1 USD $0.08075
≥10 USD $0.0665
≥100 USD $0.0646
≥500 USD $0.0627
≥1000 USD $0.05985
Inventory: 61682
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-213AC, MINI-MELF, SOD-80
Number of Pins 34
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2005
Tolerance ±3%
JESD-609 Code e3/e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish TIN/TIN COPPER
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature HIGH RELIABILITY
HTS Code 8541.10.00.50
Subcategory Voltage Reference Diodes
Max Power Dissipation 500mW
Technology ZENER
Terminal Position END
Terminal Form WRAP AROUND
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number RLZ22
JESD-30 Code O-LELF-R2
Number of Elements 1
Polarity UNIDIRECTIONAL
Impedance 30Ohm
Element Configuration Single
Diode Type ZENER DIODE
Current - Reverse Leakage @ Vr 200nA @ 17V
Power Dissipation 500mW
Case Connection ISOLATED
Max Reverse Leakage Current 200nA
Impedance-Max 30Ohm
Reference Voltage 22V
Voltage - Zener (Nom) (Vz) 21.2V
Zener Voltage 21.175V
Voltage Tol-Max 2.5%
Working Test Current 5mA
Voltage Tolerance 3%
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
