RLZTE-1115A
RoHS
RoHS compliant
RoHS compliantPackage DO-213AC, MINI-MELF, SOD-80
Category Discrete Semiconductor Products / Diodes - Zener - Single
Description
Tape & Reel (TR) ±3% Surface Mount ZENER DIODE Zener Diode 200nA @ 11V 500mW 15V 16Ohm
PDF
/
Inventory: 3910
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 0.2μA
Working Test Current 10mA
Zener Voltage 14.3V
Voltage - Zener (Nom) (Vz) 14.3V
Reference Voltage 15V
Impedance-Max 16Ohm
Case Connection ISOLATED
Current - Reverse Leakage @ Vr 200nA @ 11V
Diode Type ZENER DIODE
Impedance 16Ohm
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
Operating Temperature (Max) 175°C
Qualification Status Not Qualified
JESD-30 Code O-LELF-R2
Terminal Form WRAP AROUND
Terminal Position END
Technology ZENER
Max Power Dissipation 500mW
HTS Code 8541.10.00.50
Additional Feature HIGH RELIABILITY
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±3%
Published 2000
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Package / Case DO-213AC, MINI-MELF, SOD-80
Mounting Type Surface Mount
Mount Surface Mount
