DZ2S04700L
RoHS
RoHS compliant
RoHS compliantPackage SC-79, SOD-523
Category Discrete Semiconductor Products / Diodes - Zener - Single
Description
Zener Diodes 4.7V 5% 150mW FLT LD 0.8x1.6mm
PDF
/
Buying Options
Total Price: USD $0.08
Unit Price: USD $0.080438
≥1 USD $0.080438
≥10 USD $0.075886
≥100 USD $0.071589
≥500 USD $0.067538
≥1000 USD $0.063711
Inventory: 1167
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-79, SOD-523
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2009
Tolerance ±5%
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 150°C
HTS Code 8541.10.00.50
Max Power Dissipation 150mW
Technology ZENER
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DZ2S04V7
Number of Elements 1
Polarity UNIDIRECTIONAL
Impedance 80Ohm
Element Configuration Single
Diode Type ZENER DIODE
Current - Reverse Leakage @ Vr 2μA @ 1V
Voltage - Forward (Vf) (Max) @ If 1V @ 10mA
Max Reverse Leakage Current 2μA
Impedance-Max 80Ohm
Test Current 5mA
Reference Voltage 4.7V
Forward Voltage 1V
Zener Voltage 4.7V
Voltage Tol-Max 4.99%
Voltage Tolerance 5%
Dimensions
Height 600μm
Length 1.2mm
Width 800μm
Compliance
RoHS Status RoHS Compliant
