RoHS
RoHS RoHS compliant
Package 2-SMD, Flat Lead
Category Discrete Semiconductor Products / Diodes - Zener - Single
Description Zener Diodes 9.1V 5% 120mW FLT LD 0.6x1.4mm
PDF
/
Inventory: 9485
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Width 600μm
Length 1mm
Height 470μm

Technical

Voltage Tolerance 5%
Voltage Tol-Max 5%
Zener Voltage 9.1V
Reference Voltage 9.1V
Test Current 5mA
Impedance-Max 20Ohm
Max Reverse Leakage Current 100nA
Voltage - Forward (Vf) (Max) @ If 1V @ 10mA
Power Dissipation 120mW
Current - Reverse Leakage @ Vr 100nA @ 6V
Diode Type ZENER DIODE
Element Configuration Single
Impedance 20Ohm
Polarity UNIDIRECTIONAL
Number of Elements 1
Base Part Number DZ2709V1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology ZENER
Max Power Dissipation 120mW
HTS Code 8541.10.00.50
Min Operating Temperature -40°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Tolerance ±5%
Published 2014
Packaging Tape & Reel (TR)

Physical

Diode Element Material SILICON
Number of Pins 2
Package / Case 2-SMD, Flat Lead
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 10 Weeks
