CZRER20VB-HF
RoHS
RoHS compliant
RoHS compliantPackage 0503 (1308 Metric)
Category Discrete Semiconductor Products / Diodes - Zener - Single
Description
DIODE ZENER 20V 150MW 0503
PDF
/
Inventory: 6333
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Zener Voltage 20V
Voltage - Zener (Nom) (Vz) 20V
Impedance-Max 48Ohm
Voltage - Forward (Vf) (Max) @ If 900mV @ 10mA
Current - Reverse Leakage @ Vr 100nA @ 15V
Diode Type ZENER DIODE
Element Configuration Single
Impedance 48Ohm
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Max Power Dissipation 150mW
HTS Code 8541.10.00.50
Terminal Finish Gold (Au)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Tolerance ±3%
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Package / Case 0503 (1308 Metric)
Mounting Type Surface Mount
Mount Surface Mount
