CZRER10VB-HF
RoHS
RoHS compliant
RoHS compliantPackage 0503 (1308 Metric)
Category Discrete Semiconductor Products / Diodes - Zener - Single
Description
DIODE ZENER 10V 150MW 0503
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.259169
≥1 USD $0.259169
≥10 USD $0.244505
≥100 USD $0.230663
≥500 USD $0.21761
≥1000 USD $0.205296
Inventory: 1124
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0503 (1308 Metric)
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2011
Tolerance ±3%
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Gold (Au)
HTS Code 8541.10.00.50
Max Power Dissipation 150mW
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 30
Impedance 15Ohm
Element Configuration Single
Diode Type ZENER DIODE
Current - Reverse Leakage @ Vr 100nA @ 8V
Voltage - Forward (Vf) (Max) @ If 900mV @ 10mA
Impedance-Max 15Ohm
Voltage - Zener (Nom) (Vz) 10V
Zener Voltage 10V
Compliance
RoHS Status ROHS3 Compliant
