CMDZ5259B TR
RoHS
/
Package /
Category Discrete Semiconductor Products / Diodes - Zener - Single
Description
PDF
/
Inventory: 7412
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount YES
Diode Element Material SILICON
Number of Terminals 2
Technical
JESD-609 Code e3
Pbfree Code icon-pbfree yes
Moisture Sensitivity Level (MSL) 1
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8541.10.00.50
Subcategory Voltage Reference Diodes
Technology ZENER
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) 10
JESD-30 Code R-PDSO-G2
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Operating Temperature (Min) -65°C
Number of Elements 1
Polarity UNIDIRECTIONAL
Configuration SINGLE
Power Dissipation-Max 0.25W
Diode Type ZENER DIODE
Reference Voltage 39V
Voltage Tol-Max 5%
Working Test Current 3.2mA
Reverse Current-Max 0.1μA
Dynamic Impedance-Max 80Ohm
Voltage Temp Coeff-Max 36.66mV/°C
Knee Impedance-Max 800Ohm
Compliance
RoHS Status RoHS Compliant
