AZ23C3V3-7 image
Favorite
AZ23C3V3-7 image
Favorite
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - Zener - Arrays
Description DIODE ZENER ARRAY 3.3V SOT23-3
PDF
/
Inventory: 9986
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Weight 7.994566mg
Diode Element Material SILICON

Technical

Operating Temperature -65°C~150°C
Packaging Tape & Reel (TR)
Published 2009
Tolerance ±5%
JESD-609 Code e0
Pbfree Code no
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn85Pb15)
HTS Code 8541.10.00.50
Subcategory Voltage Reference Diodes
Power Rating 300mW
Voltage - Rated DC 3.3V
Max Power Dissipation 300mW
Technology ZENER
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 235
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number AZ23C3V3
Pin Count 3
Qualification Status Not Qualified
Number of Elements 2
Polarity UNIDIRECTIONAL
Configuration 1 Pair Common Anode
Impedance 95 Ω
Element Configuration Common Anode
Diode Type ZENER DIODE
Power Dissipation 300mW
Impedance-Max 95 Ω
Test Current 5mA
Reference Voltage 3.3V
Zener Voltage 3.3V
Voltage Tol-Max 6.06%
Voltage Tolerance 5%

Dimensions

Height 1mm
Length 3.05mm
Width 1.4mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
