GVD30503-001
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description
CAPACITOR
PDF
/
Inventory: 5035
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Surface Mount YES
Diode Element Material SILICON
Technical
Operating Temperature -55°C~125°C TJ
Published 2001
Part Status Obsolete
Number of Terminations 3
ECCN Code EAR99
HTS Code 8541.10.00.80
Terminal Position DUAL
Terminal Form GULL WING
Reach Compliance Code compliant
JESD-30 Code R-PDSO-G3
Qualification Status Not Qualified
Number of Elements 1
Diode Type Single
Capacitance @ Vr, F 6pF @ 25V 50MHz
Voltage - Peak Reverse (Max) 25V
Breakdown Voltage-Min 25V
Diode Capacitance-Nom 26pF
Quality Factor-Min 200
Q @ Vr, F 200 @ 4V, 50MHz
Variable Capacitance Diode Classification HYPERABRUPT
