MV209G
RoHS
RoHS compliant
RoHS compliantPackage TO-226-2, TO-92-2 (TO-226AC)
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description
DIODE TUNING EPICAP 30V TO92-2
PDF
/
Inventory: 6173
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-2, TO-92-2 (TO-226AC)
Surface Mount NO
Diode Element Material SILICON
Technical
Operating Temperature 125°C TJ
Packaging Bulk
Published 2006
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Additional Feature HIGH RELIABILITY
HTS Code 8541.10.00.80
Subcategory Varactors
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 260
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 3
JESD-30 Code O-PBCY-T2
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 0.2W
Diode Type Single
Capacitance @ Vr, F 32pF @ 3V 1MHz
Voltage - Peak Reverse (Max) 30V
Breakdown Voltage-Min 30V
Frequency Band VERY HIGH FREQUENCY
Diode Capacitance-Nom 29pF
Capacitance Ratio 6.5
Capacitance Ratio Condition C3/C25
Diode Cap Tolerance 10.34%
Quality Factor-Min 200
Q @ Vr, F 200 @ 3V, 50MHz
Variable Capacitance Diode Classification HYPERABRUPT
Compliance
RoHS Status RoHS Compliant
