MMBV809LT1G image
Favorite
MMBV809LT1G image
Favorite

MMBV809LT1G

ON Semiconductor
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description DIODE TUNING SS 20V SOT23
PDF
/
Buying Options
Total Price: USD $14.95
Unit Price: USD $14.95205
≥1 USD $14.95205
≥10 USD $12.2683
≥100 USD $11.88545
≥500 USD $11.50165
≥1000 USD $11.1188
Inventory: 1623
Minimum: 1
-
+

Technical Details

Supply Chain

Lifecycle Status LAST SHIPMENTS (Last Updated: 21 hours ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Diode Element Material SILICON

Technical

Operating Temperature 125°C TJ
Packaging Tape & Reel (TR)
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin (Sn)
Additional Feature HIGH RELIABILITY
HTS Code 8541.10.00.80
Capacitance 4.5pF
Subcategory Varactors
Voltage - Rated DC 20V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MMBV809
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 0.225W
Diode Type Single
Breakdown Voltage 20V
Capacitance @ Vr, F 6.1pF @ 2V 1MHz
Reverse Voltage 20V
Frequency Band ULTRA HIGH FREQUENCY
Diode Capacitance-Nom 5.3pF
Capacitance Ratio 2.6
Capacitance Ratio Condition C2/C8
Diode Cap Tolerance 15.09%
Quality Factor-Min 75
Q @ Vr, F 75 @ 3V, 500MHz

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
