MMBV105GLT1
RoHS
/
Package SOT-23-3
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description
DIODE TUNING SS 30V SOT23
PDF
/
Buying Options
Total Price: USD $22.26
Unit Price: USD $22.2604
≥1 USD $22.2604
≥10 USD $18.26565
≥100 USD $17.6947
≥500 USD $17.12375
≥1000 USD $16.5528
Inventory: 1412
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Quality Factor-Min 250
Diode Capacitance-Nom 2.15pF
Frequency Band ULTRA HIGH FREQUENCY
Reverse Voltage 30V
Power Dissipation 225mW
Diode Type VARIABLE CAPACITANCE DIODE
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 200mA
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Rated DC 30V
Subcategory Varactors
Capacitance 1.5pF
HTS Code 8541.10.00.80
Additional Feature HIGH RELIABILITY
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2009
Packaging Cut Tape (CT)
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case SOT-23-3
Mount Surface Mount
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 4 days ago)
