BB200,215
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description
DIODE VAR CAP DUAL 18V SOT-23
PDF
/
Inventory: 4097
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Diode Cap Tolerance 6%
Capacitance Ratio Condition C1/C5
Capacitance Ratio 5
Diode Capacitance-Nom 70pF
Breakdown Voltage-Min 18V
Voltage - Peak Reverse (Max) 18V
Capacitance @ Vr, F 14.8pF @ 4.5V 1MHz
JEDEC-95 Code TO-236AB
Diode Type 1 Pair Common Cathode
Configuration COMMON CATHODE, 2 ELEMENTS
Number of Elements 2
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G3
Pin Count 3
Base Part Number BB200
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish TIN
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2001
Packaging Tape & Reel (TR)
Operating Temperature -55°C~85°C TJ
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
