ZV953V2TA
RoHS
/
Package SC-79, SOD-523
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description
DIODE VARACTOR LV 250Q SOD-523
PDF
/
Inventory: 7398
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-79, SOD-523
Weight 992.233309μg
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Solder
ECCN Code EAR99
Terminal Finish MATTE TIN
HTS Code 8541.10.00.80
Capacitance 45pF
Subcategory Varactors
Voltage - Rated DC 12V
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) 260
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number ZV953
Pin Count 2
Qualification Status Not Qualified
Number of Elements 1
Polarity Standard
Element Configuration Single
Diode Type 1 Pair Common Cathode
Forward Current 100mA
Capacitance @ Vr, F 37pF @ 1.5V 1MHz
Reverse Voltage (DC) 12V
Diode Capacitance-Nom 33.5pF
Capacitance Ratio 2
Capacitance Ratio Condition C0.5/C2.5
Diode Cap Tolerance 10.45%
Quality Factor-Min 200
Q @ Vr, F 200 @ 0.5V, 50MHz
Dimensions
Height 800μm
Length 1.3mm
Width 900μm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
