ZV950V2TA
RoHS
/
Package SC-79, SOD-523
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description
DIODE VARACTOR LV 500Q SOD-523
PDF
/
Inventory: 975
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 260
Terminal Form FLAT
Terminal Position DUAL
Voltage - Rated DC 12V
Subcategory Varactors
Capacitance 9.5pF
HTS Code 8541.10.00.80
Terminal Finish MATTE TIN
ECCN Code EAR99
Termination Solder
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Q @ Vr, F 250 @ 0.5V, 50MHz
Quality Factor-Min 250
Diode Cap Tolerance 10.64%
Capacitance Ratio Condition C0.5/C2.5
Capacitance Ratio 2
Diode Capacitance-Nom 7.05pF
Reverse Voltage (DC) 12V
Capacitance @ Vr, F 7.8pF @ 1.5V 1MHz
Forward Current 100mA
Diode Type 1 Pair Common Cathode
Element Configuration Single
Polarity Standard
Number of Elements 1
Qualification Status Not Qualified
Pin Count 2
Base Part Number ZV950
Time@Peak Reflow Temperature-Max (s) 40
Physical
Diode Element Material SILICON
Weight 992.233309μg
Package / Case SC-79, SOD-523
Mounting Type Surface Mount
Mount Surface Mount
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Width 900μm
Length 1.3mm
Height 800μm
