ZMDC831BTA
RoHS
/
Package SC-70, SOT-323
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description
DIODE VARACTOR 25V 15PF SC70-3
PDF
/
Inventory: 2819
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-70, SOT-323
Weight 6.010099mg
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Capacitance 14.25pF
Subcategory Varactors
Voltage - Rated DC 25V
Reach Compliance Code unknown
Base Part Number ZMDC831
Pin Count 3
Polarity Standard
Element Configuration Common Cathode
Diode Type 1 Pair Common Cathode
Forward Current 200mA
Capacitance @ Vr, F 15.75pF @ 2V 1MHz
Reverse Voltage (DC) 25V
Diode Capacitance-Nom 15pF
Capacitance Ratio 6
Capacitance Ratio Condition C2/C20
Quality Factor-Min 300
Q @ Vr, F 300 @ 3V, 50MHz
Dimensions
Height 1mm
Length 2.2mm
Width 1.26mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
