ZC834ATA
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description
DIODE VAR CAP 47PF 25V SOT23-3
PDF
/
Inventory: 5990
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Width 1.4mm
Length 3.05mm
Height 1mm
Technical
Q @ Vr, F 200 @ 3V, 50MHz
Quality Factor-Min 200
Diode Cap Tolerance 10%
Capacitance Ratio Condition C2/C20
Capacitance Ratio 6.5
Diode Capacitance-Nom 47pF
Reverse Voltage (DC) 25V
Capacitance @ Vr, F 51.7pF @ 2V 1MHz
Forward Current 200mA
Diode Type Single
Number of Elements 1
Case Code (Imperial) 0402
Case Code (Metric) 1005
Qualification Status Not Qualified
Pin Count 3
Base Part Number ZC834A
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Rated DC 25V
Capacitance 42.3pF
HTS Code 8541.10.00.80
Additional Feature LOW NOISE
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination Solder
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Weight 7.994566mg
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
