BA783S-E3-18 image
Favorite
RoHS
RoHS RoHS compliant
Package SC-76, SOD-323
Category Discrete Semiconductor Products / Diodes - RF
Description Diodes - General Purpose, Power, Switching 35 Volt 100mA Band
PDF
/
Inventory: 1969
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case SC-76, SOD-323
Surface Mount YES
Number of Pins 2
Weight 10.290877mg
Diode Element Material SILICON

Technical

Operating Temperature 125°C TJ
Packaging Tape & Reel (TR)
Published 2015
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8541.10.00.60
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 2
Number of Elements 1
Max Current Rating 100mA
Element Configuration Single
Diode Type PIN - Single
Forward Current 100mA
Forward Voltage 1V
Peak Reverse Current 50nA
Max Repetitive Reverse Voltage (Vrrm) 35V
Capacitance @ Vr, F 1.2pF @ 3V 1MHz
Frequency Band ULTRA HIGH FREQUENCY
Resistance @ If, F 1.2Ohm @ 3mA 1GHz

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
