BA783S-E3-08
RoHS
RoHS compliant
RoHS compliantPackage SC-76, SOD-323
Category Discrete Semiconductor Products / Diodes - RF
Description
Diodes - General Purpose, Power, Switching 35 Volt 100mA Band
PDF
/
Inventory: 1894
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case SC-76, SOD-323
Surface Mount YES
Diode Element Material SILICON
Technical
Operating Temperature 125°C TJ
Packaging Tape & Reel (TR)
Published 2015
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8541.10.00.60
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 2
JESD-30 Code R-PDSO-G2
Number of Elements 1
Diode Type PIN - Single
Current - Max 100mA
Capacitance @ Vr, F 1.2pF @ 3V 1MHz
Voltage - Peak Reverse (Max) 35V
Frequency Band ULTRA HIGH FREQUENCY
Resistance @ If, F 1.2Ohm @ 3mA 1GHz
Diode Capacitance-Max 1.2pF
Compliance
RoHS Status ROHS3 Compliant
