DMV1500SDFD
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - RF
Description
Rectifiers 6 Amp 1500 Volt
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.533817
≥1 USD $0.533817
Inventory: 3296
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Voltage - Peak Reverse (Max) 1500V
Recovery Time 400 ns
Forward Voltage-Max 1V
Reverse Voltage 600V
JEDEC-95 Code TO-220AB
Peak Reverse Current 3μA
Number of Phases 1
Application HIGH VOLTAGE VERY FAST RECOVERY
Output Current-Max 6A
Max Surge Current 50A
Case Connection ISOLATED
Diode Type Standard - 1 Pair Series Connection
Max Current Rating 6A
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Number of Elements 2
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 3
Base Part Number DMV1500
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 6A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form THROUGH-HOLE
Terminal Position SINGLE
Voltage - Rated DC 1.5kV
Subcategory Rectifier Diodes
Capacitance 7pF
HTS Code 8541.10.00.80
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature 150°C TJ
Physical
Diode Element Material SILICON
Surface Mount NO
Package / Case TO-220-3 Full Pack
