DMV1500HDFD
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - RF
Description
RF DIODE STANDAR 1500V TO220FPAB
PDF
/
Inventory: 9099
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Voltage - Peak Reverse (Max) 1500V
Recovery Time 85 ns
Forward Voltage-Max 1.25V
Reverse Voltage 600V
Non-rep Pk Forward Current-Max 75A
JEDEC-95 Code TO-220AB
Peak Reverse Current 3μA
Number of Phases 1
Application HIGH VOLTAGE VERY FAST RECOVERY
Output Current-Max 6A
Max Surge Current 50A
Case Connection ISOLATED
Diode Type Standard - 1 Pair Series Connection
Max Current Rating 6A
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Number of Elements 2
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 3
Base Part Number DMV1500
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 6A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 245
Terminal Form THROUGH-HOLE
Terminal Position SINGLE
Voltage - Rated DC 1.5kV
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Physical
Diode Element Material SILICON
Surface Mount NO
Package / Case TO-220-3 Full Pack
