MMBD770T1
RoHS
/
Package SC-70, SOT-323
Category Discrete Semiconductor Products / Diodes - RF
Description
Tape & Reel (TR) Schottky - Single Single 3 RF Diode 1pF @ 20V 1MHz 1A 120mW 1V
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.173805
≥1 USD $0.173805
≥10 USD $0.163968
≥100 USD $0.154685
≥500 USD $0.145931
≥1000 USD $0.13767
Inventory: 1597
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Physical
Package / Case SC-70, SOT-323
Surface Mount YES
Number of Pins 3
Diode Element Material SILICON
Technical
Operating Temperature -55°C~125°C TJ
Packaging Tape & Reel (TR)
Published 1996
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature LOW REVERSE LEAKAGE
HTS Code 8541.10.00.60
Subcategory Rectifier Diodes
Voltage - Rated DC 70V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Reach Compliance Code not_compliant
Current Rating 1A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number MMBD770
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Polarity Standard
Max Current Rating 200mA
Power Dissipation-Max 120mW
Element Configuration Single
Diode Type Schottky - Single
Output Current 200mA
Max Reverse Leakage Current 200nA
Max Surge Current 1A
Capacitance @ Vr, F 1pF @ 20V 1MHz
Forward Voltage-Max 1V
Max Forward Surge Current (Ifsm) 1A
Frequency Band VERY HIGH FREQUENCY TO ULTRA HIGH FREQUENCY
Diode Capacitance-Max 1pF
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
